Total resistance Range | 1KΩ,2KΩ,5KΩ,10KΩ | |||||||||||
Total resistance tolerance | ±10% | |||||||||||
End resistance | 3Ω Max | |||||||||||
Resistance Taper | B(Linear) | |||||||||||
Contact resistance variation | 3% max | |||||||||||
Power Rating | 0.5W/40°C | |||||||||||
Max input voltage | 200VDC or power rating,whichever is smaller | |||||||||||
Electrical angele | 280° | |||||||||||
Insulation resistance | 100MΩ Min/DC 1000V | |||||||||||
Operating temp.range | -10°C~+85°C | |||||||||||
Independent Linearity | ±3% Max. | |||||||||||
Environment Characteristics | Slodering heart | 350°C±5°C,3sec. | ||||||||||
Temperature Characteristics | +80°C,5 hours | |||||||||||
Moisture and load life | +40°C,90~95%RH 0.5W,500 Hours | |||||||||||
temerature cycle | -10°C,+80°C ea.30 minutes 5 cycles | |||||||||||
Vibration | 10~55Hz,amplitude 1.5mm 3 directions | |||||||||||
Rotation life | 2,000,000 cycles,without rating load | |||||||||||
